Board To Board Connectors Pitch 2.0mm Dual Row Header Connector 180 Pin

Certification : ISO9001, IATF16949, ISO14001

Place of Origin : China

MOQ : 5000 pcs

Supply Ability : 10k pcs daily capacity

Delivery Time : 2 weeks

Packaging Details : blister, tube, tape and reel,

Plastic material : PBT, PA6T, LCP

contact material : brass, phosphor bronze

Current Rated : 3A

Type : Board to board

plating : tin or gold plated

Operating temperature : -40---+105 degree

Contact Now

board to board connectors Pitch 2.0mm dual row 180 pin header connector

Quick Details

Place of Origin: Guangdong, China

Model Number: P240-12XXXXXSXXXX1

Type: PCB Connector

Application: FPC

Gender: Male

Pins: 16p, 14P, 22P, 26P, 4p, 64P, 5P, 12p, 28P, 30P, 36P, 1P, 7P, 10P, 24P, 32P, 9P, 50P, 3P, 8P, 34P, 40P, 18P, 20P, 2P, 6P

Product Name: Pin Header Connector

Pitch: 2.0mm

Insulator Height for Choice: 1.0mm ,1.5mm ,2.0mm ,2.5mm

Row Number: Dual Row

Ways/Pins per row: 2 ~ 40P

Contact Material: Brass

Contact Plating: Gold (Au) or Tin (Sn) Plated over Nickel (Ni)

Housing Material: PBT, PA6T, PA9T, LCP

Certificate: RoHS Compliant/ISO9001/14001

Connector Type: PCB Connector

Supply Ability

Supply Ability: 1000000 Piece/Pieces per Month

Packaging & Delivery

Package Details: Tube, Tape & Reel, Tube +CAP, Plastic Box, Tray,

Port: Shenzhen, Hongkong

Product Name:	Pitch 2.0mm pin header connector
Description:	Pitch :2.0mm Row Number: dual row Insulator Number: one piece Oriental: straight
Insulator Height for choice:	1.0mm ,1.5mm ,2.0mm ,2.5mm
Contact Material:	Brass
Contact Plating:	Gold (Au) or Tin (Sn) Plated over Nickel (Ni)
Insulator Material:	PBT, PA6T, PA9T, LCP
Rating Current:	2.0AMP
Contact Resistance:	20mΩ Max
Insulating Resistance:	1000 MΩ Min
Withstanding Voltage:	AC 500V/Minute
Temperature:	-40° C to +105° C

Board To Board Connectors Pitch 2.0mm Dual Row Header Connector 180 Pin

Product Tags:

Board To Board Connectors Pitch 2.0mm

Dual Row Header Connector 180 Pin

Pitch 2.0mm Dual Row Header Connector
